1. All lengths support resolutions requiring 48Gbps transfer rates, including 8K60 or 10K60 HDR
2. Lightweight ABS connector assembly with 1kg retention force
3. UL CMG fire-rated cable (3m and above) for safe in-wall installations
4. Flexible design ideal for professional AV setups
5. Individually tested for consistent performance that’s ‘Connectivity Assured’
6. Gold-plated connectors for optimal signal integrity and longevity
7. Lifetime warranty for peace of mind

Data Rate: Up to 48Gbps (FRL mode) | up to 18.2Gbps (TMDS mode)
Video Resolution: Up to 8K (7680 x 4320) / 10K (10240 x 4320)
Video Refresh Rate: Up to 240 frames per second
Colour Depth: Up to 16 bits
Colour Formats: RGB 4:4:4 / Y’C_BC_R 4:2:2 / Y’C_BC_R 4:2:0
Content Protection: Up to HDCP 2.3 supported
Audio Sample Rate / Channel: Up to 192KHz
Audio Sample Size: Up to 24 bits
Audio Channels: Up to 32 channels
Audio Formats Supported: DTS Master, DTS:X, Dolby TrueHD, Dolby Atmos
Auxiliary HDMI Features Supported: Consumer Electronic Control (CEC), Auto Lip-Sync Correction, Ethernet channel, Audio Return Channel (ARC), Enhanced Audio Return Channel (eARC), High Dynamic Range (HDR), Dynamic HDR, Variable Refresh Rate (VRR), Quick Media Switching (QMS), Quick Frame Transport (QFT), Auto Low Latency Mode (ALLM), Display Stream Compression (DSC), Source-Based Tone Mapping (SBTM)

HDMI CERTIFICATION 0.5m – 9.0m PASSIVE

HDMI CTS Certification: Ultra High Speed HDMI® Cable
DPL Labs Certified Data Rate: 12.0Gbpsc, 48Gbps agg
Supported Data Rate: ≥12.0Gbpsc, 48Gbps agg (8K UHD)
Supported HDMI Clock: 1200MHz

MECHANICAL

Cable Diameter: 0.5m – 2.0m: 34 AWG 4.5mm / 0.18in Ø | 3.0m: 30AWG, 6.0mm / 0.23 | 4.0m – 5.0m: 26 AWG, 8.0mm | 0.31in Ø| 7.0m – 9.0m: 24 AWG 9.0mm | 0.35in Ø
Mounting Length: 0.5m – 2.0m: 34AWG, 59.0mm/2.3” | 3.0m: 30AWG, 59.0mm/2.3” |4.0m – 5.0m: 26 AWG, 66mm/2.6” |7.0m – 9.0m: 24 AWG, 110.5mm/4.4”
Cable Bend Radius: 0.5m – 2.0m: 34 AWG, 25.0mm/1.0” | 3.0m: 30 AWG, 25.0mm/1.0” | 4.0m – 5.0m: 26 AWG, 32.0mm/1.3” |7.0m – 9.0m: 26 AWG, 72.0mm/2.8”

CONSTRUCTION

Primary Conductors: 0.5m-2.0m: Solid 34-24 AWG OFC, length dependent / 3.0m: Solid 30-26 AWG OFC, length dependent / 4.0m-9.0m: Solid 30-24 AWG OFC, length dependent
Insulation on TMDS: Polyethelyene / Polypropylene, length dependent
Insulation on 4C + HEAC Pairs: Polyethelyene / Polypropylene, length dependent
Shielding on TMDS Pairs: AL/Mylar, 100% Coverage with 25% Overlapping
Shielding Overall: AL/Mylar, 125% Coverage + Tinned copper braid, min 85% coverage
Cable Jacket: UL CMG fire-rated PVC composite materials
HDMI Connector Shell: Anti-fatigue die cast Zn alloy, 1μ” 24K Gold plated
HDMI Connector Pins: Solid OFC, 15μ” 24K Gold plated
Termination: High Frequency Soldering
HDMI Backshell: ABS front shell with PVC injection moulded boot and strain relief

The Kordz PRO4 Passive HDMI Cable is backed by our Lifetime Guarantee that promises maintained product functionality and performance for your lifetime.
