1. UV-stabilised PE jacket with water-blocking gel filler for durability in underground installations
2. 24AWG solid OFC conductors for reliable and long lasting performance
3. ANSI/TIA-568.2-D compliant for 1Gbps up to 100m and 10Gbps up to 55m
4. Supports PoE++ up to 100W
5. 3mm diameter for flexible and easy installation in confined spaces
6. Ideal for direct burial applications, such as security cameras, Wi-Fi access points and smart doorbells
7. Convenient wooden reel packaging with metre-marked cable for precise installation
8. Compatible with existing Kordz Cat6 networking components for streamlined integration
9. Kordz quality, as backed by a 5 Year Warranty.

CONSTRUCTION

Conductor: 24AWG Solid OFC annealed bare copper wire 0.537 +0/-0.015mm
Insulation: Orange & Brown pairs – Polyethylene, 1.02 ± 0.1 mm, Blue & Green pairs – Foam PE, 1.05 ± 0.1 mm
Twisting: 4 twisted pairs, 2 single conductors paired
Twisted Pair Colour Code: 1: white / blue 2: white-orange / orange, 3: white / green 4: white-brown / brown
Cable lay up: 4 pairs with different pitches / Non-metallic cross separator (spine)
Filler: Water-resistant gel / Mylar tape
Buffer : Non-Metallic cross separator
Jacket Material: UV-stabilized Polyethylene-based composite
Outer Diameter: 6.3 +/-0.5 mm

MECHANICAL

Minimum Bend Radius: without load ≥ 25.2mm /0.99”, with load ≥ 50.4mm /1.98”
Temperature Range: During Operation: -20°C to 60ºC During Installation:  0°C to 50ºC

ELECTRICAL

DC Resistance: max. 9.38 Ω/100 m at 20°C
Resistance Unbalance: max. 5% at 20ºC
Insulation Resistance (500V): min. 5000 MΩ/Km at 20°C
Mutual Capacitance: max. 5.6 nf/100 m at 1 kHz
Capacitance Unbalance (Pair to Ground): max. 330 pf/100 m at 1 kHz
Nominal Velocity of Propagation: nom. 63% c
Test Voltage: 1kV DC / 1 min

The Kordz ONE Cat6 U/UTP Direct Burial Network Cable is backed by our 5 Year Product Guarantee
